XGN68-12 miniaturized switchgear — Product Overview
"> Among the current high-voltage switchgear, the XGN68-12 high-voltage cabinet series is a small-sized, highly insulated, and more environmentally friendly high-voltage switchgear. A complete set of equipment suitable for 3-10kv three-phase AC 50Hz single busbar and busbar segmentation.
VoltCloud Electric engineers and manufactures this equipment for utility, industrial and renewable-energy projects. Every unit is routine-tested before shipment and delivered with test records and export documentation. Ratings shown below are from our current production data — non-standard capacities, voltage ratios and loss classes are engineered to order.
Key Specifications
| Item | Value |
|---|---|
| Rated voltage | 10kv |
Need a rating that is not listed? Send us your duty sheet and we will confirm feasibility and lead time.
Features & Construction
- A complete set of equipment suitable for 3-10kv three-phase AC 50Hz single busbar and busbar segmentation.
- The main components of HJK1-12 vacuum switchgear are made of new composite insulation materials and APG process sealing technology. The structure is compact and simple, the style is novel, and the cabinet is lightweight and compact.
- It can achieve the “four remote” function, complete the distribution automation of substations, and thus achieve unmanned operation of substations.
Product Details
Used for power transmission to small and medium-sized generators in power plants, distribution in industrial and mining enterprises, and secondary substations in power systems, as well as for controlling, protecting, and monitoring the starting of large high-voltage motors.
This cabinet is a small and lightweight high-voltage cabinet in a 10KV distribution system. The cabinet width is generally 500 (520) mm, the cabinet height is 1750mm, the cabinet depth is 1000mm, and the cabinet weight does not exceed 200kg.
Due to its reasonable miniaturization design and compact structure, the application design scheme of this vacuum switchgear can be flexibly and conveniently combined, greatly saving building area and space volume, and improving the efficiency of building use.
